Name: DNX-450TR
Brand: Kenwood
SKU: DNX-450TR

Key Features

6.1″ WVGA with Touch Screen Control

Digital Radio Technology (DAB+) Built-in)

Garmin navigation built-in with 3 years free map update

Truck/camper specific navigation features

Bluetooth HFP V1.6 and high quality audio streaming built in.

HDMI/MHL terminal for High Definition Video Playback

Wireless display adapter ready

Wireless & True Mirroring ready

Built-in DSP with 7 Band Graphical Equilazer

Rear-view camera input

General Features

DIN Size	2 DIN
Disabled System Indicator (DSI)	Yes
Security Code Function ( user set)	Yes
On Screen Display (OSD) Operation	Yes
Smooth GUI	Yes
Selectable GUI Background Wallpaper	Yes
Key Illumination	Variable colour
Installer Memory	Yes
Back-up Memory	Yes
Attenuator with Smooth Volume Return	Yes
Touch Sensor Tone	Yes
Optional IR remote controller	Yes, KNA-RCDV331
Digital Clock (24H)	Yes
Built-in Bluetooth	Yes
Navigation unit built-in	Yes
DAB Tuner Built-in	Yes
Audio & Video playback from latest iPod & iPhone generation	Yes, optional parts needed
Firmware upgreadable	Yes

Variable Colour illumination	Yes
GUI colour coordinate	Yes
Colour Pallet	256
Base Colour Class	65000
Software updates (SoC)	by USB
Graphics Type	Graphics
Top Menu Customize	Yes
Background Customize	Capture x 1
Display customize	Capture x 1
R-CAM interrupt	Yes
R-CAM Caution On Screen Display	Yes
Menu text in selectable language	► English ► Spanish ► French ► German ► Italian ► Dutch ► Russian ► Portuguese ► Chinese (Simplified) ► Korean ► Thai ► Turkish ► Arabic ► Persian ► Hebrew ► Greek ► Malaysian ► Indonesian ► Polisch ► Czeh ► Hungarian

Screen Type	6.1″ Wide VGA
V.OFF/TFT Off Mode	Yes
LCD backlight	LED
Display Mode	4 Mode (Full/Just/Zoom/Normal)
Screen Adjustments	Brightness/Tint(NTSC only)/Colour/Contrast/Black Level/Sharpness
Dimmer function	Manual/Sync/Navi Sync
Visual Source Mode	DVD/Video/USB/iPod/App
Touch Panel
High Resolution VGA Display	Yes
NTSC/PAL judge	Yes (Auto)

Max. Output Power (MOSFET Power IC)	4 x 50W
Pre-out	3RCA: Front/Rear/Subwoofer
Pre-out Output Level	2V
Subwoofer Reference Level Adj.	Yes
Dual Zone/2Zone Source & Volume Control	Yes
Dual Zone (FRONT / REAR Switchable)	Yes
Source Tone Control & Memory	By Parametric Equalizer
Balance/Fader Control	Yes
Loudness Control	Yes
Att.(-20dB) with smooth Volume Return	Yes
Equalizer	Yes
Digital Sound Processor (DSP)	Yes
Beep On/Off	Yes

DSP Chip	AK7600
Position Control	Yes
Position Cabin Size	Yes
Graphic equalizer	Yes
Graphic Equalizer	7 bands
G-EQ KBS	Yes
G-EQ manual setting	Yes
G-EQ adjustable level	Yes, +9dB – -9dB
High Pass Filter (HPF)	yes
HPF Cut Off Frequency	14
HPF Cut Slope Level	4 steps
Low Pass Filter (LPF)	Yes (Non-Fading)
LPF Cut Off Frequency	14
LPF Cut Slope Level	4 steps
Source DSP Memory	Yes
Channel Level Control	Yes
Space Enhancer	Yes
SupremeV	Yes
Realizer	Yes
Auto gain control (highway sound)	Yes
Loudness	Yes
Elevation	Yes
Tweeter volume	Yes
Bass Boost	Yes
Drive EQ	Yes
Car type control
Speaker Size & Location Control	Yes
X’over network

Station Select	List
FM Reception	Yes
AM (MW/LW) Reception	Yes
Presets	24 Presets (18FM / 3LW / 3MW)
Tuning mode
Up/Down Seek/Scan	Yes
Automatic Memory Entry (AME)	Yes
FM Stereo / Mono Selector	Yes
Radio Data System	Yes
Radio Text Plus	Yes
Traffic Information	Yes
Enhanced Other Networks Function (EON)	Yes
Program Type Function (PTY)	Yes

DAB+ tuner built-in	Yes
Intelligent seek	Yes
Ensemble seek	Yes
Tuning mode / Seek mode	Auto1/Auto2/Manual
Service preset	6 ch * 3 bank presets,
Auto service memory (AME)	Yes
Service list by alphabet order	Yes
Alphabet Search	Yes
Traffic Information	Yes
DAB priority	Yes
DAB-DAB/DAB-FM auto switch	Yes
Seamless DAB-FM blending	Yes
Time Shift	Yes
DLS (Dynamic Label)	Yes
DRC (Dynamic Range Control)	Yes
PTY (Programme Type) search	Yes
PTY (Programme Type) watch	Yes
Announcement Switching (ASW) Select	Yes
TMC (Traffic Message Channel) support	Yes
Antenna power supply on/off switch	Yes

DVD Region Code	2
VCD Compatible	Yes
DVD±R/RW Compatible	Yes
CD-R/RW Compatible	Yes
CD-DA Repeat/Scan/Random play	Yes
MP3, WMA & AAC playback	Yes
MPEG1/2 Video File (.mpg) Compatible	Yes
DivX	Yes
Digital/Analog Converter	24 bit
Time Code Display	Yes
Direct Search	Yes
Resume Play / Last Position Memory	Yes
Disc Menu Direct Touch	Yes
On screen display (OSD)	Yes

Rear USB Terminal	Yes
USB Type	2.0 Full speed
Kenwood Music Editor Lite Compatible	Yes
MP3, WMA, AAC, WAV, FLAC playback	Yes
MKV: Matroska Multimedia Container	Yes
MPEG1/2/4, WMV, JPEG, H.264	Yes
JPEG picture control	Yes
JPEG slide show	Yes
Repeat/Scan/Random search	Yes
Category search	Yes
Resume play	Yes
Time code display	Yes
1A Charge Capability for Smartphone.	Yes

Made for iPod & iPhone *	Yes
USB Direct Control	with optional cable KCA-iP102
USB Direct Control (Audio, 1 wire, Lightning-connector)	with optional cable KCA-iP103
USB Direct Control (Audio & Video, 2 wire, 30-pin connector)	with optional KCA-iP202
USB Direct Control (Audio & Video, Lightning-connector)	***
Music playback	Yes
Video playback	Yes
Album art support	Yes
Music library search	Yes
Alphabet search	Yes
Control by hand	Yes
App & iPod control mode	Yes
Aha Radio Control App support	Yes
Aupeo! App Link	Yes
iPod Accessory Protocol (iAP)	over Bluetooth
iAP over Bluetooth	Yes
iTunes Radio App	yes iAP1
High speed search	Yes
Reverse browsing	Yes
Voice Control using Siri.	Yes
Works with iPod Classic *	80G, 120G & 160G
Works with iPod Video *	5th/6th generation
Works with iPod Touch *	1st >> 5th generation
Works with iPod Nano *	1st >> 7th** generation
Works with iPhone *	3 >> 5C
Bluetooth Auto Paring for iPhone	Yes
Battery charge + power control	Yes
1A current capability	Yes
* Always update to latest Apple firmware
** Apple Lightning – 30 pin adapter required

HDMI / MHL Interface	MHL (KCA-MH100)
App Control (With Touch Control)	BT HID
Aha Radio Link for Android	Yes
Aupeo! Link for Android	Yes
KENWOOD Music Control	Yes

For Map Update Only

Yes

Hands Free Profile (HPF)
Max num. of regist. phones for HFP	5 phones
2 Phones Switchable Hands Free	Yes
Audio Streaming (A2DP)	Yes
