UTE-201BT

Features

Tuner

• Memory Presets: Preset Stations (FM: 18, MW: 6, LW: 6)
• Memory: Auto Memory
• RDS
• RDS Functions: AF, TA, TP, PTY, EON
• PTY (Programme Type) Display

Bluetooth®

• Built-in Bluetooth® Module
• Hands Free Calling: HFP (Hands Free Profile)
• Streaming Music: A2DP (Advanced Audio Distribution Profile) Compatible
• Streaming Music Control: AVRCP (Audio/Video Remote Control Profile) Ver. 1.3 Compatible
• Phone Book Search
• Voice Dial Operation
• Auto Answer
• Call Waiting
• Call History Display: Phone Book Call, Dialed Call, Received Call
• Speech Volume Level Adjustment
• Hands-Free Phone Sound Setting
• Firmware Updatable
• Microphone Included

Made for iPhone® / iPod®

• Connection: USB connection (KCU-445i Required)
• Made for iPod/iPhone
• M.I.X. (Shuffle) Play: Track
• Repeat: All, Track
• Battery Charging

USB Media Connection

• Front USB Connection
• MP3, WMA, AAC, FLAC Playback
• Folder Up/Down
• M.I.X. Random Play
• Repeat: Track, Album, All
• USB AOA (Android Open Accessory) 2.0

Sound Tuning

• Subwoofer Level Adjustment
• BASS ENGINE SQ: Level Control 0-6
• Subwoofer Phase Select: 0°/180°
• Subwoofer System Select
• High Pass Filter
• Low Pass Filter
• 2V Voltage 2 PreOuts
• 10 Equalizer PreSets: Flat, Pops, Rock, News, Jazz, Electrical Dance, Hip Hop, Easy Listening, Country, and Classical
• 3-band Parametric Equalizer

General

• Power Output: 4 x 50 W High Power Amplifier
• Display LCD: 14 Segments White LCD Display 1 Line
• Control Type: Rotary Encoder Knob
• Variable RGB Illumination Buttons
• 2 PreOuts (2V, Front + Subwoofer)
• Multi Bit DAC
• Front AUX Input (3.5mm mini jack)
• Steering Wheel Remote Control Ready
• -20dB Mute
• Remote Control Ready
• Clock
• Detachable DIN Trim Plate
• Detachable Face Plate
• Dimmer
• Power Antenna Lead
• Remote Turn-On

Specifications

• Max Power Output: 4 x 50W

FM Tuner

• Tuning Range: 87.5 – 108.0 MHz

MW Tuner

• Tuning Range: 531 – 1,602 kHz

LW Tuner

• Tuning Range: 153 – 279 kHz

USB

• USB Requirements: USB 1.1/2.0
• Max. Power Consumption: 1,000 mA
• File System: FAT 16/32

Sound Tuning

• Subwoofer Level Adjustment: 0 to 15 dB
• Subwoofer Phase Setting: 0° or 180°
• High Pass Filter: Off, 80/100/120 Hz
• Low Pass Filter: Off, 80/100/120 Hz
• Bass Level Control Range: ±7 dB at 100Hz
• Bass Center Frequency: 60/80/100/120 Hz
• Bass Band Width Adjustment (Q): 4 choices (0.5=wide, 1.0=medium, 1.5=medium, 2=narrow)
• Treble Level Control Range: ±7 dB at 10 kHz
• Treble Center Frequency: 7.5k/10k/12.5k/15k Hz
• Treble Band Width Adjustment (Q): 2 choices (0.75=wide, 1.25=narrow)
• Mid Level Control Range: ±7 dB
• Mid Center Frequency: 500/1k/1.5k/2.5k Hz
• Mid Band Width Adjustment (Q): 4 choices (0.75=wide, 1.0=medium, 1.25=medium, 1.5=narrow)

General

• Power Requirement: 12V.DC
• Pre Output Voltage (Before Clipping): 2V / 10k ohms
• Aux In: 1.4V / 10k ohms
• Maximum Mounting Angle: 30°
• Weight: 0.8 kg

Dimensions

• DIN Size: 1 DIN
• Chassis Size (W x H x D): 178 x 50 x 177 mm
