CAM7

Universal miniature parking camera with the view angle of 190°, for outdoor installation IP69K, with a resolution of 800TVL, use as a rearview or front camera, durable metal body, with the option to turn the guidelines on/off and to change the left/right image orientation. The camera tilt is adjustable and horizontal or vertical surface installation is possible. The camera can also be installed without a holder (glued), the camera dimensions without the holder is just 21 x 24 x 21 mm.

Universal miniature parking camera with the view angle of 190°, for outdoor installation IP69K, with a resolution of 800TVL, use as a rearview or front camera, durable metal body, with the option to turn the guidelines on/off and to change the left/right image orientation. The camera tilt is adjustable and horizontal or vertical surface installation is possible. The camera can also be installed without a holder (glued), the camera dimensions without the holder is just 21 x 24 x 21 mm.

With a real angle of view of 190°, the BC UNI-WIDE can also look around the corner. This makes it an ideal solution for vehicles such as vans/motorhomes or trucks. This camera eliminates dangerous situations in city traffic, it is an invaluable helper for monitoring crosstraffic parking. If installed as a front, you can watch the approaching traffic even before you see the oncoming vehicles through the side window. Narrow streets and dense buildings are no longer a horror and cyclists will also feel safer.

Technical parameters:

1/4″ low light HD CMOS sensor
scanning angle: 190°
image resolution 800 TV lines
brightness F1.2
min lighting less than 0.01Lux
effective points 960×480
power supply: 12V/24V
TV system: NTSC
weather protection: IP69K
Cabling
double shielded
length 8m
terminated with a CINCH connector
slim connector 5mm
2 power connection options
from reverse light
from ACC
hole for cabeling 5mm
Operating temperature -35 ℃ to 85 ℃
ECE R10
Features:

GREEN LOOP – guide lines – disappear after cutting the loop (shown by default)
WHITE LOOP – image orientation – left/right side will swap after cutting the loop
