FT-122TLED

Fristom FT-122 T LED Universal Rear Lamp

The Fristom FT-122 T LED is a versatile, low power consumption rear lamp designed for use on a wide range of vehicles operating within a 12-30V electrical system. This 4-functional lamp includes a rear position light, STOP light, indicator, and an integrated number plate light, all housed within a colourless lampshade with dedicated red and amber filters.

Key Features

• Voltage range: 12-30V DC
• Functions: Rear position light, STOP light, indicator, and number plate light
• Colour filters: Red filter for STOP light, amber filter for indicator
• Low power consumption for energy efficiency
• 1 metre cable included for easy installation
• Homologated with European E9 certification and EMC compliance
• Shock-resistant polycarbonate lampshade
• Reverse polarity protection for enhanced durability
• Can be mounted horizontally or vertically

Technical Specifications

• Rear position light current consumption: 0.06A (12V), 0.06A (24V)
• Rear position light power: 0.75W (12V), 1.5W (24V)
• Rear position light + number plate light current consumption: 0.14A (12V), 0.14A (24V)
• Rear position light + number plate light power: 1.65W (12V), 3.3W (24V)
• STOP light current consumption: 0.08A (12V), 0.08A (24V)
• STOP light power: 1W (12V), 2W (24V)
• Indicator current consumption: 0.08A (12V), 0.08A (24V)
• Indicator power: 1W (12V), 2W (24V)

Certifications

• European E9 homologation
• ElectroMagnetic Compatibility (EMC) certificate

Installation and Usage

The FT-122 T LED rear lamp is suitable for mounting in either horizontal or vertical positions, offering flexibility for various vehicle configurations. Its robust construction with shock-resistant polycarbonate material ensures durability in demanding automotive environments. The included 1 metre cable facilitates straightforward wiring during installation.
